File:IM2 Plus Ack Bug.png
Error creating thumbnail: Unable to save thumbnail to destination
Original file (761 × 363 pixels, file size: 20 KB, MIME type: image/png)
Red marker is at start of IRQ acknowledge cycle which is immediately seen by the ASIC (INTn goes up) : vector is 0x06 Purple marker is at the effective cycle where the Z80 sample the vector, and where the ASIC sees a second acknowledge. Vector is now 0x04.
